Speaker & Tweeter RGB LED Ring Kit

Upgrade your custom audio build with Gorilla Knobz Smart RGB LED Rings for speakers and tweeters. This kit is designed to add bright, clean, show-quality lighting to your 6.5" speakers and 2", 3", or 4" tweeters.

These are not basic single-color LED rings. Gorilla Knobz Smart Rings feature RGB lighting with chasing effects, solid colors, and hundreds of dynamic color modes. Control your lights through the BanLanX app using Bluetooth, or use the included remote control depending on the module option selected.

Key Features

• RGB LED rings for 6.5" speakers and tweeters

• Available for 2", 3", and 4" tweeter setups

• Bluetooth app control through BanLanX

• Chasing effects, solid colors, and dynamic lighting modes

• Adjustable colors, brightness, and effect speed

• Multiple kit options available

• V2, V3, and V4 module options

• Great for doors, T-panels, pillars, and custom car audio builds

Module Options

V2 Standard Module
Includes remote control, smart module, and 10 ft power cord.

V3 Upgraded Module
Features an improved wiring setup with integrated remote wire and two 5 ft LED connectors. This option is ideal for T-panel or pillar installs and helps prevent battery drain when wired correctly.

V4 Module
Bluetooth-controlled module option for a cleaner setup with advanced app control. Same connectors as v3 module.

What’s Included?

Package contents depend on the kit option selected at checkout.

• Smart RGB LED rings based on selected quantity

• Tweeter rings based on selected size and kit option

• RGB control module based on selected module option

• Remote control, depending on module selected

• Power wiring

Installation Notes

The power cord includes a red and black wire that can be connected to a proper 12V power source. It can be connected near your amplifier power input area, but it should not be connected to speaker outputs, speaker terminals, or speaker wires.

Each ring includes male and female connectors, making it easy to connect multiple rings together in sequence.

When installing the rings behind your speakers or tweeters, carefully align the screw holes before tightening everything down. Misalignment can damage the rings during installation.

Ring Dimensions

6.5" Speaker Ring
Outer Diameter: 7"
Inside Cutout: 6.11"
Thickness: 0.50"

2" Tweeter Ring
Recommended for tweeters under 3" diameter
Outer Diameter: 3.4"
Inside Cutout: 2.4"
Thickness: 0.50"

3" Tweeter Ring
Recommended for tweeters under 4" diameter
Outer Diameter: 4"
Inside Cutout: 2.98"
Thickness: 0.50"

4" Tweeter Ring
Recommended for tweeters under 5" diameter
Outer Diameter: 4.75"
Inside Cutout: 3.875"
Thickness: 0.50"

Known Fitment

The 3" tweeter ring is designed to fit models such as:

• Skar VX35-ST

• DS18 PRO-TW120

• Deaf Bonce T25

• Deaf Bonce T25 V2

The 2" tweeter ring is designed to fit models such as:

• Deaf Bonce AT-32 Sport

Please confirm your speaker or tweeter measurements before ordering to make sure the rings fit your setup properly.

Can I Add More Rings Later?

Yes. The LED rings use male and female connectors, so additional rings can be added later. Individual rings are available separately on our website.
